CO2 Multi Sensor Mini Display
The CO2 Multi Sensor Mini Display is designed to provide an added remote display option in conjunction with the main CM-7005 tablet. This device works cohesively with our CO2 Multi-Sensor Safety System.
*The CO2 Multi-Sensor Safety System is a plug and play set, however requires additional components to create a fully integrated system. See "CO2 Multi Sensor System Parts" below for each component or contact a CO2Meter expert for more information on your application.
CO2 Multi Sensor System Parts- CO2 Multi Remote Relay (CM-7002)
- Sensor Unit Add On (CM-7003)
- CO2 Main Tablet (CM-7005)
- Exterior Horn Strobe Add On (CM-7004-OUT)
- CM-7000 Solenoid Shut Off Valve (SV-1029)
- CM-7000 Solenoid Shut Off Valve (1/2") (SV-1030)
Electrical
- Wall Power Plug: 110-220 VAC 50/60 Hz to 12 VDC Power Adapter
- Power Input: 48-58 VDC
- 48-58VDC hard-wired power option
- Power Consumption: 30W
- Can be connected to a UPS for Battery Backup
- Max distance any sensor or horn/strobe can be from the tablet is 250 ft.
Warranty
- 1 year - See CO2Meter Terms and Conditions.
Accessories
CM-7002 - Remote Relay Key Switch - the Remote Relay Key Switch unit add-on provides a unique push-button and key switch to mute and reset latch for all sensors connected to the tablet.
CM-7003 - CO2 Sensor - the CO2 Sensor add-on provides easily addressable sensor capabilities directly to the CO2 multi sensor tablet (up to 12+ sensors per device).
CM-7005 - Main Tablet Only - the CO2 Multi Sensor tablet provides visual indication of gas concentration levels to prevent hazard from occurring in your establishment.
CBL-7002 - Reset Unit Relay Cable - the CAT5 relay cable provides additional configuration for added sensor capabilities of the CM-7000. This cable is designed to be configured with the CM-7002 Reset Unit and can be wired to the CM-1026-5,6 Strobe Towers and SV-1027 Solenoid Valve.
CM-7004-OUT- an audible/visual strobe alarm that can be used for all exterior placements.
CM-1026-5,6 - CO2 Storage Strobe Tower - designed to provide a flashing indicator, and audible alarm with any of our CM-7000 systems.
SV-1029 Solenoid Safety Shut Off Valve - (3/8 inch valve) designed to be utilized with our CM-7000 CO2 Multi-Sensor System, and can be directly wired to the SV-1029 safety shut-off valve via main tablet or sensor unit relays.
SV-1030 Solenoid Safety Shut Off Valve - (1/2 inch valve) designed to be utilized with our CM-7000 CO2 Multi-Sensor System, and can be directly wired to the SV-1030 safety shut-off valve via main tablet or sensor unit relays.
Calibration Gas - Because of MDOT regulations, calibration gases must be shipped from a certified gas supplier. You can order calibration gas from your local supplier or you can order the following products from CalGasDirect.com
-
