Tongdy CO2 Monitor with Relay
The Tongdy CO2 Monitor lets you simply and easily monitor and control indoor air quality. Use it to visually monitor air quality with its easy-to-read colored LEDs that quickly change from green to yellow to red as indoor air quality changes. When air quality gets too poor, its built-in relay can be used to turn on ventilation to bring in fresh, outdoor air.
- Real-time Carbon Dioxide Level Control & Monitor
- Six Colored LEDs to Easily Check Indoor IAQ
- Built-in Relay to Control Ventilation
With its one-button on/off/auto ease of use and industry-standard 24V power requirements, the Tongdy CO2 Monitor with Relay is perfect for homes, offices, meeting rooms, classrooms, or anywhere monitoring and controlling indoor air quality is important for occupant's comfort.
ABOUT CO2 STORAGE SAFETY CODES
This device will NOT meet requirements for CO2 monitoring in the NBIC, NFPA, or IFC regulations. The accuracy of the sensor in the TIM10 is not designed for safety situations. Refer to our CO2 Safety Products page for devices that meet your needs.
Call us at (877) 678-4259 toll-free or email us to speak with our technical sales team about purchasing the correct device.
Specifications
- Non-Dispersive Infrared (NDIR)
- Sampling Method: Diffusion
- Range: 0 – 2,000 ppm
- Accuracy: ± 30 ppm ± 3 % of measured value
- Life Expectancy: > 15 years
Display
- 1st green light <600ppm
- 1st and 2nd green lights 600-800ppm
- 1st yellow light 800-1200ppm
- 1st and 2nd yellow lights 1200-1400ppm
- 1st red light 1400-1600ppm
- 1st and 2nd red lights >1600ppm
Electrical / Mechanical
- Power Input TON-0007: 24VAC/VDC
- Power Input TON-0007-WP: 110-220VAC
- Output Relay: <240VAC/30VDC 3A Switching Current
- Output Relay Control: 800ppm to 1500ppm via jumpers
- Additional Outputs: Use Model TON-0001
- Housing: PC/ABS fireproof plastic; protection class: IP30
- Maintenance Interval: No Maintenance Required
- Dimensions: 100mm (H) × 80mm (W) × 28mm (D) or 2x4" wire box
- Standard: CE-Approved
Warranty
- 1 year - See CO2Meter Terms and Conditions.
