Space Pro: Smart CO2, VOC, Temperature, Humidity Monitor for Commercial Buildings

Specifications

Carbon Dioxide (CO2) Sensor:

• Sensing Technology: NDIR (non-dispersive infrared technology)
• Measurement Range: 400–5000 ppm.
• Settling time: ~7 days
• Accuracy: ±50 ppm ±5 % at 400-2000 ppm within 50 - 95 °F (10 – 35 °C) and 0 – 80
  %RH, after initial settling time of 7 days.
• Resolution: 1 ppm

Particulate Matter (PM) Sensor:

• Sensing Technology: laser scattering based optical particle counter
• Particle size detection range: 300 nm to 10 μm
• Measurement Range: 1-1000 μg/m³
• PM1 and PM2.5 Measurement Accuracy: below 150 μg/m³: ± (5 μg/m³ + 15 %),
  above 150 μg/m³: ± (5 μg/m³ + 20 %).
• PM10 Measurement Accuracy: below 100 μg/m³: ± 25 μg/m³, above 100 μg/m³: ± 25% (under evaluation)
• Calibrated with: a GRIMM reference instrument using cigarette smoke source.
• Resolution: 1 μg/m³
• Classified as: Class 1 Laser per IEC60825-1 Ed. 3. This device complies with 21
  CFR 1040.10 and 1040.11, except for conformance with IEC 60825-1 Ed. 3., as
  described in Laser Notice No. 56

VOC Sensor:

• Sensing Technology: Metal-oxide based gas sensor
• Measurement range: 0-10 000 ppb
• Settling time: ~7 days
• Accuracy: 20 µg/m3 + 15% at values between 1 and 500 µg/m3
• Resolution: 1 μg/m3

Relative Humidity:

• Technology: Solid state sensor
• Resolution: 0.5 %RH
• Accuracy: ±3 %RH at 77 °F (25 °C) within 20-80 %RH

Temperature Sensor:

• Technology: Solid state sensor
• Resolution: 0.1 °F (0.1 °C)
• Accuracy: ±0.9 °F at 77 °F / ±1.8 °F from 32-140°F (±0.5 °C at 25 °C / ±1 °C
  from 0-60 °C)

Pressure Sensor:

• Technology: Solid state sensor
• Pressure Accuracy: ±0.6 mbar/hPa (0.02 inHg) range 500-1100 mbar/hPa
  (14.77-32.48 inHg)

Light Sensor:

• Technology: Solid state sensor
• Measurement range: 0 - 100 %

Noise Sensor:

• Dynamic range: 35 - 120 dBA SPL


Radio Specifications - BlueTooth Low Energy

• Output power: <5 mW
• Frequency Range (MHz): 2400.0 - 2483.5

Radio Specifications - AirThings Smart Link

• Output power: <25 mW
• Frequency range (MHz): Europe 868 - 870, North America 902-928
  Singapore 920-923, Hong Kong 920-923, Australia 923-928, India 865-870

Device Specifications:

• Recommended Operating Conditions:  39 to 104°F (4 to 40°C) H
• Humidity: 0% to 85% (non condensing)
• Power: 6 AA Batteries or USB-C

• Weight: 360g (with batteries, without cable)

• Dimensions: 6.69 (W) x 1.30 (L) x (H) 3.54

Warranty

• 1 year - See CO2Meter Terms and Conditions
